Risk Assessment

In this tool it is possible to explore APRIORA’s interal database related to Predicted No Effect Concentration (PNEC) values and to perform the final risk for each river section. Three different type of risk are considered:

• Environmental Risk Assessment (ERA)

• Human Health Risk Assessment (HHRA)

• Antimicrobial Resistance Risk Assessment (AMR-RA)

Additionally, a Component Cumulative Risk Index (CCRI) is calculated.

Environmental Risk Assessment (ERA)

ERA evaluates ecological impact by calculating the Risk Quotient (RQ) according to formula (5).

(5)\[RQ_{ERA} = \frac{PEC}{PNEC_{ERA}}\]

With:

• \(RQ_{ERA}\) = Risk Quotient of Environmental Risk Assessment [-]

• \(PEC\) = Predicted Environmental Concentration [\(ng/L\)]

• \(PNEC_{ERA}\) = Predicted No Effect Concentration for ERA [\(ng/L\)]

An RQ value greater than 1 indicates a potential risk, requiring deeper look into wheter a regulatory concern truly exists. Since PNEC values are often estimates based on limited species data and assessment factors, they can be supplemented with QSAR (Quantitative Structure-Activity Relationship) screeneing tools or NORMAN database values when experimental data is missing. Ultimately, the process prioritizes substances that are persistent or bioaccumulative, as these compounds can disrupt ecosystems even at very low levels.

Human Health Risk Assessment (HHRA)

The Human Health Risk Assessment (HHRA) evaluates the potential risks of lifelong exposure to APIs through accidental ingestion of surface water and the consumption of locally caught fish. This assessment relies on the RQ, which compares total human intake from these pathways to an Oral Reference Dose (RfD), the level considered safe for human consumption. To calculate intake, the model incorporates country-specific fish consumption rates, gastrointestinal absorption fractions, and Bioconcentration Factors (BCF) often derived from QSAR models. While the resulting RQ values are typically low, indicating a significant safety margin, the methodology can be used to determine “safe” surface water concentrations by back-calculating the concentration at which the RQ would equal one. The calculation expressed in formula (6) is then very similar to what shown in formula (5).

(6)\[RQ_{HHRA} = \frac{PEC}{PNEC_{HHRA}}\]

With:

• \(RQ_{HHRA}\) = Risk Quotient of Human Health Risk Assessment [-]

• \(PEC\) = Predicted Environmental Concentration [\(ng/L\)]

• \(PNEC_{HHRA}\) = Predicted No Effect Concentration for HHRA [\(ng/L\)]

Antimicrobial Resistance Risk Assessment (AMR-RA)

The Antimicrobial Resistance Risk Assessment (AMR-RA) evaluates the potential for antibiotic residues to select for resistant microbial populations using a RQ. This calculation is very similar to what explained in Environmental Risk Assessment (ERA): a PNEC value is compared with PEC values and a value exceeding 1 indicates risk (formula (7)).

(7)\[RQ_{AMR-RA} = \frac{PEC}{PNEC_{AMR-RA}}\]

With:

• \(RQ_{AMR-RA}\) = Risk Quotient of Antimicrobial Resistance Risk Assessment [-]

• \(PEC\) = Predicted Environmental Concentration [\(ng/L\)]

• \(PNEC_{AMR-RA}\) = Predicted No Effect Concentration for AMR-RA [\(ng/L\)]

Component Cumulative Risk Index (CCRI)

In addition to individual PNEC calculations, a Component Cumulative Risk Index (CCRI) is calculated to provide an overall assessment when multiple APIs are selected. This single value summarizes the combined risk from all tested substances in each river section, giving the user a quick, comprehensive view of the situation. The CCRI is calculated using formula (8).

(8)\[CCRI = \log(RQ_{sum} + 1) \cdot \left( 1 + \frac{(RQ > 1)_{sum}}{RQ_{sum}} \right)\]

With:

• \(CCRI\) = Component Cumulative Risk Index [-]

• \(RQ_{sum}\) = sum of RQs tested for n substances [-]

• \((RQ > 1)_{sum}\) = sum of RQs tested for n substances that are greater than 1 [-]

Input data

The following input file is necessary:

• river_accumulation.shp (from Accumulation)

The key fields for this process are the ones containing concentration values. For each river section, formula (5), (6) or (7) is applied and a RQ is calculated.

Workflow

1. Go in the Processing Toolbox and look for the APRIORA plugin. Click on API emission and open 5 - Risk Assessment

2. Choose river_accumulation.shp as input for River accumulation

3. Select the fields containing the concentration of APIs for the risk assessment. This selection should include only columns containing concentrations in ng/L.

4. Select which type of risk you would like to calculate (multiple selection is possible)

5. Go to the PNEC database window to either confirm or change the PNEC values which will be used in the calculations of RQ

6. To change something, simply double click on a number and update the value

7. To add a new substance, click on the “+” icon and fill out the corresponding row

In case the user would like to share one of the PNEC tables with other users:

8. Click on the three dots in the top left corner and select “Export table (for sharing only)”

In case the user would like to import one of the PNEC tables from other users:

9. Click on the three dots in the top left corner and select “Import external removal rate table”

10. Go back to the Risk Assessment window and click on Calculate Risk Assessment

Video: Worflow of the Risk Assessment tool.

Output data:

• risk_assessment.shp

The output is a line shapefile containing the same geometry of river_accumulation.shp. The attribute table instead, has the same API concentration columns plus RQ fields of the selected risk(s) for both conditions (mean flow and mean low flow) for each API selected. Finally, the last two columns represent CCRI for the selected risk(s) for the same two conditions.

Table 7 shows an example of a part of the attribute table where PEC of Carbamazepine and Diclofenac was calculated.

Table 7 Example of attribute table of risk_assessment.shp (PNEC of Carbamazepine = 2500 ng/L).

conc_Carb [1]	conL_Carb [2]	era_Carb [3]	eraL_Carb [4]	CCRI_era [5]	CCRI_era_L [6]
18.12	109.95	0.0072	0.0439	2.972	6.157
4.677	28.379	0.0018	0.0113	0.633	3.698
4.634	28.119	0.0018	0.0112	0.6295	3.6834
3.0412	18.453	0.0012	0.0073	0.4544	3.0009
2.8870	17.517	0.0011	0.0044	0.4357	2.9206

[1]

Concentration of Carbamazepine in normal conditions [\(ng/L\)]

[2]

Concentration of Carbamazepine in low flow conditions [\(ng/L\)]

[3]

Environmental Risk Assessment of Carbamazepine in normal conditions [-]

[4]

Environmental Risk Assessment of Carbamazepine in low flow conditions [-]

[5]

CCRI for ERA in normal conditions [-]

[6]

CCRI for ERA in low flow conditions [-]

The style of risk_assessment.shp is based on the value of one of the RQ and it is possible to change it by going on “Layer Properties” -> “Symbology”.
